Fixed price per cylinder
Transparent calculation: base price per cylinder × cylinder count. Surcharges for oversize bores or special alloys are shown in the quote – no surprises.
Fixed price per cylinder · from 1 cylinder up
Cylinder liners, press-fit and honed to final dimension.
Scoring, seizure, excess clearance? We re-sleeve your engine block – dry (press-fit) or wet liners, including honing to your spec. Fixed price per cylinder, from one cylinder up. Package shipping for 1–2 cylinders, freight for 3+ (up to 50 kg).
LIVE · All engine types
from 1cylinder possible
24 mo.warranty
DHL/Frt.shipping up to 50 kg
The cylinder liner specialist
Why MIK Motoren is the right address for cylinder re-sleeving.
Sleeving is precision work. Incorrectly pressed liners ruin an engine on first firing. We've re-sleeved 400+ engine blocks – with hydraulic press, measuring benches and in-house honing machine.
Dry & wet, every engine type
Press-fit liners (dry) or wet liners with O-ring seat: passenger car, truck, marine, tractor, vintage, stationary. Bore diameters from 70 mm to 160 mm.
Honing to final dimension included
After press-fitting, each liner is honed to your target dimension – plateau honing for optimal piston bed-in. Roundness and cylindricity logged in the protocol.
Shipping up to 50 kg
Up to 2 cylinders: DHL package (24–48h). From 3 cylinders: freight up to 50 kg. Fully insured. Inbound and outbound photo-documented.
24-month warranty
On press-fit and honing. No mileage limit when the engine is assembled correctly. Measurement protocol with every block.
Turnaround: 3–7 business days
From arrival of your block. Pre-booked jobs usually on the machine next day. Express handling on request against surcharge.
How it works
3 steps to a freshly sleeved block.
Fixed price in the configurator. Block in. Block back.
1
Enter cylinder count & dimensions
How many cylinders, engine type, bore size – we calculate the fixed price instantly.
Step 1 · ~5 min.
2
Ship in your block
You get the shipping label. Package up to 2 cyl., freight from 3 cyl. Or bring it directly to Waldbröl – workshop reception 08:00–17:00.
Step 2 · 1–3 business days shipping
3
Press-fit + hone
We measure, press-fit, hone to spec, log the protocol and ship back. Measurement protocol and photo documentation per cylinder.
Step 3 · 3–7 business days
Price orientation
What does cylinder liner installation cost?
Fixed price per cylinder, depends on bore size and liner type. Exact price in 5 min. in the configurator.
Service
Fixed price from
Typical range
1 cylinder (standard, dry)
Bore 70–95 mm, press-fit liner
from €175
€175 – €220
4 cylinders (inline-four)
Typical passenger car / truck engines
from €680
€680 – €890
6 cylinders (inline or V6)
BMW, Mercedes, Audi V6
from €1,020
€1,020 – €1,320
8 cylinders (V8)
AMG, Ford V8, US V8
from €1,320
€1,320 – €1,740
Wet liners (surcharge)
Truck, marine, tractor – incl. O-ring seat
+ €56/cyl.
per block
Oversize / special alloy
Oversize bore, Nikasil, high-alloy
+ 42–84 €/cyl.
on request
All prices net, plus VAT. Price includes press-fit + honing to spec + measurement protocol. Shipping (1–2 cyl. package / 3+ cyl. freight up to 50 kg) as a separate line in the quote.
For which engines
Every block, every engine type.
Tractor 3-cylinder, 2.0 TFSI, BMW M57 or V8 muscle car: if the bores are scored, we sleeve the block.
Passenger car petrol
Passenger car diesel
Truck / commercial
Agricultural
Marine diesel
Stationary engine
Vintage
US V8
Motorcycle (>500cc)
Industrial
Military
Motorsport
Reviews
Workshops & enthusiasts on MIK Motoren.
Professional workshops, vintage specialists and ambitious private builders.
★★★★★
„Sent in a 2.0 TFSI block with four deep score marks. Measurement protocol before and after sleeving, photos of every cylinder, roundness under 0.01 mm. This is how it's done. Engine has run 22,000 km without oil consumption since."
M
Marco P.Independent workshop · Dortmund
★★★★★
„As a vintage guy, clean sleeving is worth its weight in gold. MIK did my 1968 Mustang 351W V8 in 6 days, bore exactly to my piston spec. Price was exactly what the configurator quoted."
J
Jens W.Ford Mustang 1968 · Hannover
★★★★★
„John Deere 6-cylinder agricultural diesel, wet liners with O-rings. Fast, clean, fair price. Every block from now on goes to them – EU-wide pickup for workshops saves us freight."
H
Heinz M.Agricultural workshop · Schleswig-Holstein
FAQ
Frequently asked questions on cylinder liner service.
Key answers around cylinder liners, press-fitting, honing and shipping.
What does press-fitting a cylinder liner cost?
From around €249 net per cylinder – including press-fit and honing to your target dimension. Price depends on bore size (70–160 mm), liner type (dry / wet) and whether oversize bores or special alloys (Nikasil, high-alloy) are requested. The binding fixed price comes back in 5 min. from our configurator.
When does sleeving make sense vs. oversize pistons?
Oversize pistons are cheaper, but only possible if the engine was designed for them and the wall thickness still permits another oversize step. In case of deep score marks (> 0.25 mm), seizure, excess clearance > 0.12 mm or if the block has already been bored to max oversize, there's no way around sleeving. We check this on the incoming block and give an honest recommendation before starting work.
Dry or wet liner – what's the difference?
Dry (press-fit) liners are interference-pressed sleeves with no direct coolant contact. Standard in passenger-car engines. Wet liners sit with their outer surface in the coolant jacket and are sealed with O-rings – typical in trucks, marine, tractors. We do both.
How long does press-fitting and honing take?
3–7 business days from arrival of the engine block, depending on cylinder count and workload. Pre-booked jobs usually on the machine the next day. Express handling on request against surcharge. You get photo documentation on inbound and outbound, plus the measurement protocol.
How do I ship my engine block?
Up to 2 cylinders: DHL package (free, shipping label via email). From 3 cylinders: freight up to 50 kg – we arrange pickup, you just need a pallet. Or bring it in person to Waldbröl (workshop reception Mon–Fri 08:00–17:00, Sat 09:00–13:00). All transports insured.
Which engines and bore sizes do you handle?
Bores from 70 mm to 160 mm: passenger-car inline-four to V12, marine diesel, truck, tractor, stationary, vintage and motorsport engines. Special requests (Nikasil, high-alloy, extreme oversize) – please call.
Do I get a measurement protocol?
Yes, with every job. We measure bore, roundness, cylindricity and surface roughness after honing. The protocol is digital (PDF) and ships with the block. For later questions (engine failure, warranty claim) the protocol is your evidence.
What warranty do you give on the sleeving?
24 months warranty on press-fit and honing. No mileage limit when the engine is assembled correctly by a workshop. For private DIY assembly, statutory warranty applies.
Do you work as a supplier for independent workshops?
Yes. B2B terms with framework contract from 10 engines/year: faster turnaround, fixed prices, door-to-door pickup. Enquiries by email or phone.
Inside the shop
Where your engine is rebuilt.
Photos say more than certifications. This is where we work, this is where your engine comes together.
Enter cylinder count – get fixed price.
Non-binding. Free. In 5 minutes you know what your block costs.
Calculate fixed price per cylinder now
